ShadowControl

Vision-Based Humanoid Robot Teleoperation

CMU Build18 2025

Carnegie Mellon University

Abstract

We built a real-time teleoperation system that lets an operator control a humanoid robot through body movements. The system uses MediaPipe to estimate the operator's pose from a webcam, calculates joint angles using plane projection methods, and sends commands to the robot's servos. The main challenges were handling gimbal lock in the angle calculations and achieving smooth motion despite sensor noise. We built everything from scratch in one week at CMU's Build18 hackathon, 3D printing our own parts and assembling all the hardware ourselves for around $610.

Method

The system has three main stages: pose estimation, joint angle retargeting, and motion control.

Pose Estimation

We use MediaPipe's BlazePose to extract 33 body landmarks from each video frame. We run the "heavy" model rather than "lite" because it gives more stable 3D positions, which matters more than raw speed for teleoperation. We set high confidence thresholds (0.9) to filter out unreliable detections.

Joint Angle Retargeting

The main challenge is converting 3D pose coordinates into robot joint angles. We compute angles by projecting limb vectors onto anatomically meaningful planes. For example, shoulder abduction (raising arm sideways) is computed by projecting the upper arm onto the horizontal plane and measuring the angle from vertical.

A key problem is gimbal lock: when the arm points along a projection axis, the computed angle becomes unstable. We detect this by checking if the projection magnitude falls below 30% of the full vector length. When that happens, we return NaN and hold the previous angle instead of sending jittery commands.

def compute_shoulder_abduction(shoulder, elbow):
    arm_vec = normalize(elbow - shoulder)

    # Project onto XY plane (horizontal)
    proj_xy = [arm_vec.x, arm_vec.y, 0]

    # Gimbal lock check
    if magnitude(proj_xy) < 0.3 * magnitude(arm_vec):
        return NaN

    return atan2(proj_xy.x, proj_xy.y)

Motion Control

Raw retargeted angles are noisy, so we apply three techniques:

• Exponential smoothing with alpha=0.4 to filter high-frequency noise
• Rate limiting at 30 degrees per frame to prevent mechanical shock
• Dead zone of 2 degrees to eliminate servo hunting from small noise

On startup, we read the robot's current positions and use them as the baseline, so the robot does not jump to some default position when teleoperation begins.

Demo

Demo at Build18 expo.

Results

Latency

End-to-end latency from human movement to robot movement is around 130ms. The breakdown:

Observations

• 130ms latency is noticeable but still usable for teleoperation.
• The smoothing and rate limiting make the motion look fluid rather than jittery.
• Gimbal lock detection prevents erratic behavior at edge poses.
• The servos stayed below 60C during 10+ minutes of continuous operation.

Hardware

Cost

Building It

Some photos from the build week:

Team

Acknowledgments

This project was built at CMU Build18 2025. Thanks to K-Scale Labs for the open-source robot design files, and to the Build18 organizers for the workspace and support.
